Inverter DC-AC

KSTA300HS24

Part number: I10300HS24

Pure sine wave Inverter 300W - 24Vdc Input Voltage

Application fields

Bus / Vehicles

Data sheet

Pure sine wave Inverter 300W - 24Vdc Input Voltage

Wave form Pure sine wave
Signalling Fault, Output present
Available contact Remote ON/OFF
Audible noise at 1m (dBA) <45
IP rating IP20
Cooling Automatic forced cooling
Working temperature (°C) -20 +60
Soft start Yes
Efficiency (%) >90
Absorption from the battery empty (A) 0,4
Output frequency (Hz) 50
Output voltage 230 Vac
Power (W) 300
Surge rating (W/s) 600 / 1
Input Voltage DC 24 Vdc
Installation Tower, Wall mount
Integrated charger -
Harmonic distorsion (%THD) <3
Protections Short circuit, Thermal, Undervoltage, Overvoltage
Connection Screw, USB 5Vdc 0,5A
Standard provided equipment Battery cables, Remote ON/OFF cable 1,5 mt
"E" Mark Yes
Standards EN 55035, EN 61000-3-2, EN 61000-3-3, EN 62040-1, EN 62109-1 , Directive (ECE) R10-05, EN 62109-2, EN 55032
Warranty 2 Year
Package quantity (pieces) 1
Height (mm) 55
Depth (mm) 187
Width (mm) 110
Weight (Kg) 0,83
